Pluviometer series
1. overview
The rain gauge is a resolution of artificial observation type rainfall 1m∑m, its bearing the rain mouth assembly is installed on the outdoor storage boφttle placed indoors, for artificial precipitation observation, which can be conveniently used for heavy rain and rainstorm☆ observation and possible flash floods, landslides warning.
2. composition and working principle
The rainfall device by the 200mm caliber standard bearing the rain mouth 1, 2 mesh, stai↓nless steel outer cylinder 3, stainless steel mounting bracket assembly 4, wγater pipe 5, water pipe fixing clips 6, 7, a water storage bottle cover on the 8 glπobal level (see Figure 1).
The rain mouth assembly is mounted on the roof, or outdoor s∑torage bottle installed in the interior of precipitation ∑when bearing the rain mouth to undertake water through t₩he filter, water pipe into the water storage bottl∞e, the effective volume of water storage bottle for 200mm precipitation, the scale on the boαttle is 1mm precipitation, can be conveniently used for artificial observation and precipitation due to heavy rainfall flash floods triggered landslides≈ warning. After each rainfall, only the water in the water bottle is poured out, and then th♦e water pipe is re inserted into the water bottle to ≥observe the next precipitation process.
This type of plastic alloy bearing rain gauge is port and a filter screen made of i±mported high strength material manufacturing, using imported high strength PC ★material storage bottle, the outer cylinder and bearing manufacturing fasteners are stainless₩ steel material, instrument appearance and durable.
3. main technical parameters
Size of 3.1 rain mouth: diameter: 200 (0 ~ 0.6) mm;
Cutting edge angle: 40~450;
Calibration value of 3.2 water bottle: 1mm precipitation;
3.3 water pipe size: diameter 10mm, length (standard) 5m;
Size of 3.4 rain cylinder: 208mm * 300mm;
3.5 use environment: -10 ~ 75; relative humidity; less than 90% (40).
