Gate level gauge series
1 functional uses
KS-10 digital gate opening instrument for rivers, lakes, reservoirs, locks, hydropower staσtions and water supply and drainage engineering of the gate opening measuremen∞ts, can use the coaxial connection, sprocket connection, gear coupling and other ≈direct connection and the measured gate coupling, the instrument itself has an integraΩted design of stroke control switch, can be directl♦y set stroke limit control point. At the same time, this series of equipment and with the gate hoist control device, an electric display connected display and control system; and the compuΩter system connected water level measurement and control system, integrated station gate, hydropower; connection and communication machine, digital terminal equipment as hydrological automatic m<onitoring system, hydrological telemetry system using satellite.
This instrument can be used to measure the opening degree and limit the stroke of the flat gate,← arc brake, screw hoist, hoist.
2 working principle
KS-10 series digital gate opening instrument is composed of mechanical or photoelectric encoder, s∑troke switch device and adaptive coupler. The gate movement through th€e coupler drive rotary encoder, and can output mechanical stroke gate position coεrresponding to the gray code encoding signal and the corresponding on-off signal.
The resolving power of KS-10 series digital gate ope↔ning instrument is 0.5cm or 1cm. The working proceεss is as follows: when the gate for vertical movement or rotation, coupler is co±nnected with gate is synchronous movement, then drive the rotation of £the coupler spindle encoder, corresponding to the output encoder and the electrical socke≈t through the rotating position of gate position encoding signal ( gray). For the flat gate, the output signal by hardware or software for ©decoding, display and observation; for an arc or herringbon£e gate, by electrical display or computer on the gray automatic conver§sion and digital processing output.
While the encoder rotates, the axis of the integrated stroke switch device rotates synchronous≤ly through the reducer, such as reaching the limit state, that is®, the output signal of "through" or "off" is sent to the controller.
3 technical parameters
A. measurement range: KS-10-B (mechanical encoder):0 ~ 10m;
KS-10-G (optical encoder):0 ~ 20m;
B. resolution: 1cm (mechanical encoder);
0.5, 0.1cm (photoelectric encoder);
C. output code: 10 ~ 13bit encoder: gray machine;
Photoelectric encoder: Gray code 13 ~ 16bit;
E. transmission distance: less than 500 meters;
F. coupling: shaft coupling coupling, gear coupling or sproc♥ket coupling;
G. output form: (1) on-off contact: 3A/220VAC;
(2) OC gate: 30mA/30VDC.
3.1 communication interface (optional)
(1) RS485 interface: MODBUS protocol or other.
(2) analog signal output from 4 to 20mA.
3.2 use environment
A environmental temperature: -25 ~ 85 c;
B relative humidity: <90% (40 C);
D power supply voltage: 12 ~ 24VDC.
3.3 electric display (optional)
